More PPU coding on the NES/Famicom

After getting sprites working in Lisp on the NES for our “What Remains” project, the next thing to figure out properly is the background tiles. With the sprites you simply have a block of memory you edit at any time, then copy the whole lot to the PPU each frame in one go – the tiles involve a bit more head scratching.

The PPU graphics chip on the NES was designed in a time where all TVs were cathode ray tubes, using an electron gun to build a picture up on a phosphor screen. As this scans back and forth across the screen the PPU is busy altering its signal to draw pixel colours. If you try and alter its memory while its doing this you get glitches. However, its not drawing all the time – the electron gun needs to reset to the top of the screen each frame, so you get a window of time (2273 cycles) to make changes to the PPU memory before it starts drawing the next frame.

0014
(Trying out thematic images and some overlapping text via the display list)

The problem is that 2273 cycles is not very much – not nearly enough to run your game in, and only enough to update approx 192 background tiles per frame as DMA is a slow operation. It took me a while to figure out this situation – as I was trying to transfer an entire screenful in one go, which sort of works but leaves the PPU in an odd state.

The solution is a familiar one to modern graphics hardware – a display list. This is a buffer you can add instructions to at any time in your game, which are then acted on only in the PPU access window. It separates the game code from the graphics DMA, and is very flexible. We might want to do different things here, so we can have a set of ‘primitives’ that run different operations. Given the per-frame restriction the buffer can also limit the bandwidth so the game can add a whole bunch of primitives in one go, which are then gradually dispatched – you can see this in a lot of NES games as it takes a few frames to do things like clear the screen.

There are two kinds of primitives in the what remains prototype game engine so far, the first sets the tile data directly:


(display-list-add-byte 1)
(display-list-add-byte 2)
(display-list-add-byte 3)
(display-list-end-packet prim-tile-data 0 0 3)

This overwrites the first 3 tiles at the top left of the screen to patterns 1,2 and 3. First you add bytes to a ‘packet’, which can have different meanings depending on the primitive used, then you end the packet with the primitive type constant, a high and low 16 bit address offset for the PPU destination, and a size. The reason this is done in reverse is that this is a stack, read from the ‘top’ which is a lot faster – we can use a position index that is incremented when writing and decremented when reading.

We could clear a portion of the screen this way with a loop (a built in language feature in co2 Lisp) to add a load of zeros to the stack:


(loop n 0 255 (display-list-add-byte 0))
(display-list-end-packet prim-tile-data 0 0 256)

But this is very wasteful, as it fills up a lot of space in the display list (all of it as it happens). To get around this, I added another primitive called ‘value’ which does a kind of run length encoding (RLE):


(display-list-add-byte 128) ;; length
(display-list-add-byte 0) ;; value
(display-list-end-packet prim-tile-value 0 0 2)

With just 2 bytes we can clear 128 tiles – about the maximum we can do in one frame.

Pixel Quipu

The graphviz visualisations we’ve been using for quipu have quite a few limitations, as they tend to make very large images, and there is limited control over how they are drawn. It would be better to be able to have more of an overview of the data, also rendering the knots in the right positions with the pendants being the right length.

Meet the pixelquipu!

ur018

These are drawn using a python script which reads the Harvard Quipu Database and renders quipu structure using the correct colours. The knots are shown as a single pixel attached to the pendant, with a colour code of red as single knot, green for a long knot and blue as a figure of eight knot (yellow is unknown or missing). The value of the knot sets the brightness of the pixel. The colour variations for the pendants are working, but no difference between twisted and alternating colours, also no twist direction is visualised yet.

hp017

Another advantage of this form of rendering is that we can draw data entropy within the quipu in order to provide a different view of how the data is structured, as a attempt to uncover hidden complexity. This is done hierarchically so a pendant’s entropy is that of its data plus all the sub-pendants, which seemed most appropriate given the non-linear form that the data takes.

ur037

e-ur037

We can now look at some quipus in more detail – what was the purpose of the red and grey striped pendants in the quipu below? They contain no knots, are they markers of some kind? This also seems to be a quipu where the knots do not follow the decimal coding pattern that we understand, they are mostly long knots of various values.

ur051

There also seems to be data stored in different kinds of structure in the same quipu – the collection of sub-pendants below in the left side presumably group data in a more hierarchical manner than the right side, which seems much more linear – and also a colour change emphasises this.

ur015

Read left to right, this long quipu below seems very much like you’d expect binary data to look – some kind of header information or preamble, followed by a repeating structure with local variation. The twelve groups of eight grey pendants seem redundant – were these meant to be filled in later? Did they represent something important without containing any knots? We will probably never know.

UR1176

The original thinking of the pixelquipu was to attempt to fit all the quipus on a single page for viewing, as it represents them with the absolute minimum pixels required. Here are both pendant colour and entropy shown for all 247 quipu we have the data for:

all

entropy-local

Procedural weave rendering

We’ve been working on new approaches to 3D rendering ancient weaves, using Alex’s new behavioural language (which describes a weave from the perspective of a single thread) as the description for our modelling. This new approach allows us to build a fabric out of a single geometric shape, where warp and weft are part of the same thread.

toothpaste-mix

This is mix of tabby and 2:2 twill, created by this code:

warp 12 24 ++ [TurnIn] ++ threadWeftBy'' Odd (rot 3) ([Over,Under]) 12 12 ++ threadWeftBy'' Odd (rot 3) ([Over,Over,Under,Under]) 12 12

I’m still learning this language, but more on that soon. This line produces an large list of instructions the weave renderer uses to build it’s model, turning the thread and shifting it up and down as it crosses itself.

In the video in his last post Alex describes using this to mix two separate weaving techniques together, which is one of our main reasons for developing this language – existing weave simulations cannot replicate the weaving technology of the ancient Greeks who for example, combined tablet and warp weighted weaving in the same fabric.

The second problem with weave simulations is shown by the following screenshot from a popular existing system:

wxsg2b

Fabrics modelled in this way are considered to infinitely repeating sections with chopped off threads. There is no consideration for the selvedge at the edge of the fabric – which as we’ve shown in our past research is almost like a completely separate weave system of it’s own, and rarely considered by notation systems or modelling (and often left to the weaver to ‘livecode’). Here is a different view of the same fabric:

toothpaste-edge

We can also now introduce other changes to the yarn structure, for example modifying the width using a sine wave.

toothpaste-yarnwidth

I still have a few glitches to fix as you can see above, but here is a video of the development process from the first script, getting the polygons lined up, fixing the turning, adding over/under, reading Alex’s code and finally lining everything up.

3D warp weighted loom simulation

One of the main objectives of the weavecoding project is to provide a simulation of the warp weighted loom to use for demonstrations and exploration of ancient weaving techniques. Beyond the 4 shaft loom dyadic calculator we need to show the actual process of weaving to explain how the structures and patterns emerge. Weaving is very much a 3D process and these visualisations fail to show that well. It also needs to be able to be driven by the flotsam tangible livecoding hardware so running on a Raspberry Pi is another requirement.

Sketch and rendering

I’ve decided to make use of the Jellyfish procedural renderer to build something fast and flexible enough, while remaining cross platform. Jellyfish is a lisp-like language which compiles to a vector processing virtual machine written in C++, and approaches speeds of native code (with no garbage collection) while remaining very creative to work with, similar to fluxus livecoding. Previously I’ve only used it for small experiments rather than production like this, so I’ve needed to tighten up the compiler quite a bit. One of the areas which needed work (along with function arguments which were coming out backwards!) were the conditional statements, which I removed and replaced with a single if. Here is the compiler code at the lowest level which emits all the instructions required:

;; compiler code to output a list of instructions for (if pred true-expr false-expr)
(define (emit-if x)
  (let ((tblock (emit-expr (caddr x))) ;; compile true expression to a block
        (fblock (emit-expr (cadddr x)))) ;; compile false expression to block
    (append
     (emit-expr (cadr x)) ;; predicate - returns true or false
     (emit (vector jmz (+ (length tblock) 2) 0)) ;; if false skip true block
     tblock
     (emit (vector jmr (+ (length fblock) 1) 0)) ;; skip false block
     fblock)))

Then I can implement cond (which is a list of different options to check rather than one) as a purely syntactic form with a pre-processor function to create a series of nested ifs before compiling them:

;; preprocessor to take a cond list and convert to nested ifs
(define (preprocess-cond-to-if x)
  (define (_ l)
    (cond
      ((null? l) 0)          ;; a cond without an else returns 0
      ((eq? (caar l) 'else)  ;; check for else clause to do
          (cons 'do (pre-process (cdr (car l)))))
      (else (list 'if (pre-process (caar l)) ;; build an if
          (cons 'do (pre-process (cdr (car l))))
                  (_ (cdr l)))))) ;; keep going
  (_ (cdr x))) ;; ignores the 'cond'

Here’s an example of the if in use in the loom simulation at the ‘top’ level – it gets the current weaving draft value for the weft and warp thread position and uses it to move the weft polygons forward or back (in the z) a tiny amount to show up on the correct side of the warp.

(define calc-weft-z
    (lambda ()
        (set! weft-count (+ weft-count 1))
        (set! weft-z
              (if (> (read-draft) 0.5)
                  (vector 0 0 0.01)
                  (vector 0 0 -0.01)))))

One of the reasons I’m writing about all these levels of representation is that they feel close to the multiple representations present in weaving from draft to heddle layout, lift plan, fabric structure and resulting pattern.

Evolving butterflies game released!

toxic

The Heliconius Butterfly Wing Pattern Evolver game is finished and ready for it’s debut as part of the Butterfly Evolution Exhibit at the Royal Society Summer Exhibition 2014. Read more about the scientific context on the researcher’s website, and click the image above to play the game.

The source code is here, it’s the first time I’ve used WebGL for a game, and it’s using the browser version of fluxus. It worked out pretty well, even to the extent that the researchers could edit the code themselves to add new explanation screens for the genetics. Like any production code it has niggles, here’s the function to render a butterfly:

(define (render-butterfly s)
  (with-state
   ;; set tex based on index
   (texture (list-ref test-tex (butterfly-texture s)))
   ;; move to location
   (translate (butterfly-pos s))
   ;; point towards direction
   (maim (vnormalise (butterfly-dir s)) (vector 0 0 1))
   (rotate (vector 0 90 90))      ;; angle correctly
   (scale (vector 0.5 0.5 0.5))   ;; make smaller
   (draw-obj 4)                   ;; draw the body
   (with-state          ;; draw the wings in a new state
    (rotate (vector 180 0 0))
    (translate (vector 0 0 -0.5))  ;; position and angle right
    ;; calculate the wing angle based on speed
    (let ((a (- 90 (* (butterfly-flap-amount s)
                      (+ 1 (sin (* (butterfly-speed s)
                                   (+ (butterfly-fuzz s)
                                      (time)))))))))
      (with-state
       (rotate (vector 0 0 a))
       (draw-obj 3))              ;; draw left wing
      (with-state
       (scale (vector 1 -1 1))    ;; flip
       (rotate (vector 0 0 a))
       (draw-obj 3))))))          ;; draw right wing

There is only immediate mode rendering at the moment, so the transforms are not optimised and little things like draw-obj takes an id of a preloaded chunk of geometry, rather than specifying it by name need to be fixed. However it works well and the thing that was most successful was welding together the Nightjar Game Engine (HTML5 canvas) with fluxus (WebGL) and using them together. This works by having two canvas elements drawn over each other – all the 2D (text, effects and graphs) are drawn using canvas, and the butterflies are drawn in 3D with WebGL. The render loops are run simultaneously with some extra commands to get the canvas pixel coordinates of objects drawn in 3D space.

News from egglab

9,000 players, 20,000 games played and 400,000 tested egg patterns later we have over 30 generations complete on most of our artificial egg populations. The overall average egg difficulty has risen from about 0.4 seconds at the start to 2.5 seconds.

Thank you to everyone who contributed their time to playing the game! We spawned 4 brand new populations last week, and we’ll continue running the game for a while yet.

In the meantime, I’ve started working on ways to visualise the 500Mb of pattern generating code that we’ve evolved so far – here are all the eggs for one of the 20 populations, each row is a generation of 127 eggs starting at the top and ordered in fitness score from left to right:

viz-2-cf-0-small

This tree is perhaps more useful. The ancestor egg at the top is the first generation and you can see how mutations happen and successful variants get selected.

viz-2-cf-1-6-tree-small

Egglab – pattern generation obsession

I’m putting the final pieces together for the release of the all new Project Nightjar game (due in the run up to Easter, of course!) and the automatic pattern generation has been a focus right up to this stage. The challenge I like most about citizen science is that along with all the ‘normal’ game design creative restrictions (is it fun? will it work on the browser?) you also have to satisfy the fairly whopping constraints of the science itself, determining which decisions impact on the observations you are making – and being sure that they will be robust to peer review in the context of publication – I never had to worry about that with PlayStation games :)

variation

pattern2gen

With this game, similar to the last two, we want to analyse people’s ability to recognise types of pattern in a background image. Crucially, this is a completely different perception process from recognition of a learned pattern (a ‘search image’), so we don’t want to be generating the same exact egg each time from the same description – we don’t want people to ‘learn’ them. This also makes sense in the natural context of course, in that an individual bird’s eggs will not be identical, due to there being many many additional non-deterministic processes happening that create the pattern.

The base images we are using are wrapped Perlin noise at different scales, and with different thresholds applied. These are then rotated and combined with each other and plain colours with the browser’s built in composite operations. Ideally we would generate the noise each time we need it with a different random seed to make them all unique, but this is way too slow for HTML5 Canvas to do (pixel processing in Javascript is still painful at this scale). To get around this we pre-render a set of variations of noise images, the genetic program picks one of four scales, and one of two thresholds (and one without threshold) and we randomly pick a new variation of this each time we render the egg. The image at the top shows the variation that happens across 6 example programs. Below are some of the noise images we’re using:

noise-patterns

Raspberry Pi: Built for graphics livecoding

I’m working on a top secret project for Sam Aaron of Meta-eX fame involving the Raspberry Pi, and at the same time thinking of my upcoming CodeClub lessons this term – we have a bunch of new Raspberry Pi’s to use and the kids are at the point where they want to move on from Scratch.

This is a screenshot of the same procedural landscape demo previously running on Android/OUYA running on the Raspberry Pi, with mangled texture colours and a cube added via a new livecoding repl:

IMG_20140108_232857

Based on my previous experiments, this program uses the GPU for the Raspberry Pi (the VideoCore IV bit of the BCM2835). It’s fast, allows compositing on top of whatever else you are running at the time, and you can run it without X windows for more CPU and memory, sounds like a great graphics livecoding GPU to me!

Here’s a close up of the nice dithering on the texture – not sure yet why the colours are so different from the OUYA version, perhaps a dodgy blend mode or a PNG format reading difference:

IMG_20140108_232914

The code is here (bit of a mess, I’m in the process of cleaning it all up). You can build in the jni folder by calling “scons TARGET=RPI”. This is another attempt – looks like my objects are inside out:

IMG_20140109_004111
